Suitable for Cruise, Energy, Merchant, and Ferry.

• Global Connectivity:Global coverage via Inmarsat's L-band satellite network.
• Diverse Service Support:Simultaneously supports data, voice, SMS, and fax, meeting all communication needs.
• High Access Speed:Data speeds up to 432 kbps, supporting IP Streaming at various levels (8 to 256 kbps).
• Integrated Wi-Fi:Easily connect any device via Wi-Fi without additional hardware.
• Reliable Hardware:Robustly designed to withstand all marine weather conditions, meeting IP56 standards.
• Rack Mount Installation:Easily integrates into a 19" server rack, compatible with other network and service systems.
• Global Support Services:3-year parts and 2-year labor warranty, with a support network in over 45 countries.

Specifications

• 97 x 50 x 13cm
  • ADU (Antenna Unit): 73.3cm x 79.7cm (28.8in x 31.4in)
  • BDU (Below Deck Unit): 31.5cm x 19cm x 4.2cm (10.7in x 10.4in x 1.7in)
• Weight:
  • ADU: 29.5kg (65lbs)
  • BDU: 1.5kg (3.3lbs)
• Performance:
  • Standard IP: Up to 432 kbps
  • IP Streaming: 8, 16, 32, 64, 128, 256 kbps
  • Transmit Frequency: 1626.5 MHz - 1675.0 MHz
  • Receive Frequency: 1518.0 MHz - 1559.0 MHz
• Power Supply:
  • DC Input: 10.8V - 32V
  • Max Power: 120W
• Operating Temperature: -20°C to +55°C
  • ADU: -13°F to +131°F (-25°C to +55°C)
  • BDU: 5°F to +131°F (-15°C to +55°C)
• Water Resistance:
  • ADU: IP56
  • BDU: IP31

Advantages

• Compact Installation:19" rack cabinets help keep equipment tidy and convenient on board.
• Flexible connectivity:Supports multiple devices simultaneously, suitable for communication and entertainment needs.
• High durability:Rigorously tested to Inmarsat standards, ensuring stable operation in all maritime conditions.

Supports communication in complex and high-security environments.
