Suitable for Cruise, Energy, Merchant, and Ferry.

• Simple Maritime Connectivity: Intellian and Inmarsat have partnered to provide an easy connectivity solution with standardized equipment, a single global network, and an intuitive user interface.
• Integrated Below-Deck Unit: The GX60 comes with an integrated GX modem, minimizing installation space and supporting wireless management via Wi-Fi through the Aptus app. Additionally, it features an integrated 8-port Ethernet switch, providing VLAN capabilities in a single unit.
• Superior Speed: The Global Xpress satellite network is the world's first high-throughput satellite system, delivering Megabit speeds rather than Kilobit speeds at an affordable price.
• Top Tier Compliance: The device meets CE, FCC, and various other maritime standards such as EN60945, EN60950.
• Fast Installation: With lifting straps, the Aptus GUI, and an integrated below-deck unit, the GX60 can be installed rapidly in just 4 hours.
• One-Touch Commissioning: The system is pre-configured, enabling connection to the network in just 30 seconds from power-on with no post-installation configuration required.

Specifications

• Frequency:
  • Receive (Rx): 19.2 - 20.2 GHz
  • Transmit (Tx): 29.0 - 30.0 GHz
• 97 x 50 x 13cm
  • Antenna diameter: 65 cm
  • Radome dimensions: 83 cm x 96 cm
• Weight:
  • ADU: 37 kg
  • Below Deck Equipment: 5 kg
• Antenna Features:
  • 3-axis Stabilized System (Azimuth, Elevation, Cross-level).
  • Elevation Angle: -20° to +110°.
  • Rotation Speed: 50°/sec.
  • G/T: 17.2 dB/K.
• Power Supply:
  • 100 - 240 VAC, 50/60 Hz.
  • Power Consumption: 180 W.
• Additional Features:
  • Integrated GX modem.
  • 8-port Ethernet switch with VLAN capability.
  • Compatible with FB250/500.
  • Remote access support via Wi-Fi and Aptus application.

Product Advantages

• Uninterrupted Global Connectivity:The Intellian GX60 provides global coverage with high speeds on the Global Xpress network.
• Compact Design:Suitable for vessels with limited space.
• Easy Installation:Reduces installation time and costs with a pre-integrated system.
• Meets the Highest Standards:The device is tested and certified by reputable organizations.

Supports communication in complex and high-security environments.

• Suitable for commercial vessels, fishing vessels, yachts, and vessels requiring broadband connectivity at sea.
• Supports business applications, vessel management, and crew entertainment needs.
